Connector taxonomy

Browse by connector technology.

Micro-D and MIL-DTL-38999 Series III are the live technical beta datasets today; every other category remains a roadmap item until its evidence base is ready.

Live beta

Micro-D

High-reliability rectangular Micro-D families with evidence-backed contact count, mounting, termination, filtering, temperature and selected RF attributes.

20 public families · 8 technical lineages
Search Micro-D → LIVE BETA

Circular / MIL-DTL-38999

Series III environmental discovery is live with alternate-source qualification tiers. QPL-qualified, MIL-compliant/non-QPL and Series III-style candidates are separated; unknown combinations never pass as verified technical candidates.

Series III · /20 · /24 · /26 · QPL status · non-QPL candidates · insert arrangement · pin/socket · keying
Search D38999 Series III → Roadmap

Board-to-board

Mezzanine, rugged board-level, stacking and high-speed systems.

pitch · stack height · contacts · rows · data rate
Request coverage → Roadmap

Wire-to-board

Signal and power families terminating wire or cable to a PCB.

contacts · pitch · wire gauge · current · termination
Request coverage → Roadmap

RF / Coax

General coaxial and microwave connector coverage beyond Micro-D coax.

impedance · interface · frequency · VSWR · mounting
Request coverage → Roadmap

Fiber Optic

Rugged and high-density optical connector technologies.

fiber count · mode · technology · insertion loss · sealing
Request coverage → Roadmap

Power

High-current and power interconnect systems.

current · voltage · contacts · wire gauge · hot-plug
Request coverage → Roadmap

Hybrid

Connector systems combining signal, power, RF and/or fiber.

media types · contacts · shell · sealing · configuration
Request coverage →
Why category-specific attributes? RF needs impedance and frequency; fiber needs optical attributes; circular connectors need shell and coupling data. ConnectorAtlas uses one search experience with a category-aware technical schema behind it.
